DuraTech Model 2009EL Industrial Tub Grinder
Industrial Disposal Supply is proud to offer the DuraTech 2009 Tub grinders in a new stationary model. The versatile 2009 Tub grinder is now available with electric motor drives. A 400 hp soft start main drive motor as well as a 75 hp motor to power the hydraulic system are available in various voltages to fit your power grid specifications. These Electric motors provide steady power with no emissions, little maintenance, and reduced noise levels. The PT Tech Torque limiter protects the motor and hammermill from overloads, and costly repairs. The stationary units are available as skid mounted units or as a mobile unit with a pintle hitch.
Additional Information
Motor-Tub Drive 400hp/380V/60HZ- South Korea Only
Motor-Hydraulic drive 75hp/380V/60HZ- South Korea Only
Motor-Tub Drive 400hp/380V/50HZ
Motor-Hydraulic drive 75hp/380V/50HZ
Motor-Tub Drive 400hp/4600V/60HZ
Motor-Hydraulic drive 75hp/460V/60HZ
Hydraulic Oil Capacity 50 Gallons (189.3 Liters)
Tub Governor Electro-Hydraulic Sensing
Tub Speed Sensor Magnetic Sensor
Tub Width 9’ 6-3/8” (2.91 m) at Flare
Tub Depth 40” (1.02 m)
Tub Diameter at Base 7’ 6” (2.27 m)
Tub Wall 3/16” (.476 cm) Thick
Tub Floor 1/4” (.635 cm) Thick
Tub Drive Hydraulic Orbit Motor
Safety Switches Tub Tilt in relationship to Hammermill operation
Belly Conveyor 30” (76.2 cm) Wide
Discharge Conveyor 21’ 6” (6.55 m) Top Drive L- 24” (60.96 cm) Wide
Hammermill Opening 41” x 25” (104.14 cm x 63.5 cm)
Hammermill Drive Belt and pully through Torque Limiter
Rotor Length 40” (101.6 cm)
Rotor Plates 16” (40.64 cm) in Diameter 1” (2.54 cm) Thick
Rotor – Shaft Diameter 4-1/2” (11.43 cm) Stress Proof Steel
Bearings 3-1/2” (8.89 cm) Pillow Block Bearings
Hammer Rods 1-1/2” (3.43 cm) Diameter
Hammers 20 Fixed Single Bolt, or 40 swinging hammers
Screens 1” (2.54 cm) Thick Split Screens
Screen area 2,240 Sq in (14,451.6 sq cm)
