Hood 8000 Heavy Duty Loader
Industrial Disposal Supply is a registered Hood Equipment dealer and has the professional knowledge and expertise to help you find the right solution for your disposal needs. The Hood 8000 Series is a heavy-duty loader capable of lifting 11,900 lbs. See below for additional information on the Hood 8000.
Additional Information
Lift Capacity: 11,900 lbs.
Specifications
Booms
Standard boom length: 22 feet
Main knuckle sections: fabricated high tensile steel pivot diameter of 3 inches
Stabilizers
Pad size: 12 inches by 12 inches
Spread 9’10” at ground level
Cylinder size: 3-1/2 inches with bore 40-inch stroke by 2-inch rod
Both stabilizers are telescopic individually controlled stabilizers automatic load locks maximize stability on uneven terrain stabilizers easily operated from main control position
Hydraulic System – main boom cylinder 6” bore x 2-1/2” rod jib boom cylinder 6” bore x 30” stroke x 2-1/2” rod all cylinder barrels are heavy wall tubing reservoir: 38 gallons with oil cooler (standard equipment) continuous rotation high-pressure manifold
Filter – double return 10 micron mounted in reservoir
Pumps – gear pump
Working Pressure – 2,250 PSI
Lever Control Standard
Pilot control system optional
Hoses – All pressure hoses are constructed of 4-wire braided hose high pressure tubing is used in non-flex areas
Frame Structure – Octagon construction: fabricated high-tensile steel
Operations Platform – features open grate steel flooring and leg guard for safety
Swing Motor – planetary swing drive gearbox with a large 30” turntable bearing
Weight – 6,100 lbs.
